Mitsubishi Injection Molding Machine Screw And Barrel As Assemby

Ask Latest Price
Video Channel
Brand Name :Bloom
Model Number :BLM
Certification :ISO 9001
Place of Origin :Jiangsu,China
MOQ :1pc
Price :Negetation
Payment Terms :T/T
Supply Ability :1000mm/month
Delivery Time :30 to 45 days
Packaging Details :Packing in wooden case
Material :38CrMoAlA,42CrMo,9Cr18MoV
Application Field :Household,Agriculture,Industry,Building,Auto parts
Applied Polymers :PE,PA,PET,PVC,PC,ABS,PBT,PEEK,Teflon
Screw Treatment :Nitrided,Bimetallic,PTA,HOVF,Tool steel,HSS,PM Steel
Reinforced Additives :Less than 65% Glass Fibre
Hardness :58-64HRC
more
Contact Now

Add to Cart

Find Similar Videos
Bimetallic / Nitrided Conical Twin Screw Barrel For Extruder 00:34
Bimetallic / Nitrided Conical Twin Screw Barrel For Extruder
Corrosion Resistant Bimetallic Screw Elements And Barrel For Plastic Extruder Of Masterbatch Fluororubber 00:39
Corrosion Resistant Bimetallic Screw Elements And Barrel For Plastic Extruder Of Masterbatch Fluororubber
Type 75 Twin Screw Extruder Elements For Engineering Plastic Extruder Spare Parts 00:53
Type 75 Twin Screw Extruder Elements For Engineering Plastic Extruder Spare Parts
Parallel Twin Screw Barrel For Inflating Food Extruder Double Co Rotation Screws 00:46
Parallel Twin Screw Barrel For Inflating Food Extruder Double Co Rotation Screws
Spare Parts Screw Element For Twin Screw Extruder Anti Corrosion 00:46
Spare Parts Screw Element For Twin Screw Extruder Anti Corrosion
Parallel Twin Plastic Extruder Screw And Barrel Multiple Feed 00:29
Parallel Twin Plastic Extruder Screw And Barrel Multiple Feed
Bimetallic Accessories Complete Set Screw Segments, Barrel And Liner for lead-acid battery separators 00:27
Bimetallic Accessories Complete Set Screw Segments, Barrel And Liner for lead-acid battery separators
Bimetallic Screw Barrel For Small Plastic Injection Molding Machine 00:17
Bimetallic Screw Barrel For Small Plastic Injection Molding Machine
【Twin Screw Extruder Parts】High-Performance Bimetallic Barrel for High-Wear Extrusion Applications 01:50
【Twin Screw Extruder Parts】High-Performance Bimetallic Barrel for High-Wear Extrusion Applications
Extruder Spare Parts Nickel Based Alloy Composite Extruder Liner Sintered Alloy 00:34
Extruder Spare Parts Nickel Based Alloy Composite Extruder Liner Sintered Alloy
View Product Description

Mitsubishi Injection Molding Machine MEIII Series Spare Parts Screw And Barrel As Assemby

1 . Description

We are the manufacturer of supplier of screw and barrel in china,including designing,manufacturing and sales for these products,we can make any specification of extruder screw barrel and injection molding screw barrel for Engle,Nigrobossi,KMD,NPM,BOY,Haitian,Demag,HUSKY, Nippon Steel, Toshiba, Nissei,Mitsubishi and etc. We also can supply all types of screw and barrel according to your different requirements.

Screw diameter:Φ15mm-Φ360mmL/D=15-56
Length of screw and barrel/cylinder:8000mm

According to different material and plastic products to design different screw structure ,compress rate and L/D.
According to different material and plastic products to design different Barrel with exhaust system and IKV force load system.
2 . Technical Parameter
Base Material 1)38CrMoAlA(JIS SACM645);2)Cr12MOV(JISSKD-11) ;
3)4Cr5MoSiV1(JIS SKD-61) ;4)42CrMo(AISI4140)
Bimetallic Alloy Materials 1)Fe-based alloy2)Ni-based alloy/Deloroalloy
3)Co-based alloy4)NiCo-based alloy
5)Tungsten carbide/Wolframcarbide
Double-alloylevel Level A - containing Tungsten of40%
Level B - containing tungsten of 25%
Level C - containing tungsten of15%
Surface Treatment Heat Treatment
High FrequencyTreatment
Nitriding treatment(120Hours):
Depth of Nitrided Layer: 0.5-0.8mm
Hardness of Nitrided Layer: 900-1020Hv(HRC56°-65°)
HardChrome Plating treatment:
Thickness of Hard Chrome Plating Layer:0.05-0.10mm
Hardness ofHard Chrome Plating Layer: ≥950HV
Nickel alloyplating.treatment:
Bimetallic barrel / Cylinder: Centrifugal Casting(Inlay Alloy)
BimetallicScrew: Plasma Alloy Coating Spraying
Depth of Bimetallic Layer: >2mm
Hardness of Bimetallic Layer: HRC55°-72°
Spraying corrosion wear-resisting dual metallayers

3 . Material Application

1)GeneralPlastics
2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc
3)PA + GF(GlassFiber)
4)Flame-resistant Reinforced Plastics
5)Modified EngineeringPlastics
6)All kinds of Mixed Recycled Material(in Scrap or Granule), PVC +30% CaCo3, etc

4 . Material & Processes of screw barrel for plastic extruder

Alloy-steel of High-quality
1)38CrMoAlA
2)42CrMo
3)9Cr18MoV
4)CW6Mo5Cr4V2
5)Quality Duplex Stainless Steels
6)GH 113
7)Quality Powder Metallurgy Raw Materials
8)Cold/Thermal Spray Hard Metal process
9)Advanced nitriding Process
10)Corrosion & Abrasion Resistance Bimetal Spraying Process

5 . Technology Specification of screw barrel for plastic extruder

1)Hardness After Hardening & Tempering:HB240-290

2)Hardness of nitride layer:HV850-1000
3)Nitrided Case Depth:0.45-0.7mm
4)Nitrided Brittleness:Less Than Grade 2
5)Surface Roughness:Ra0.4
6)Screw Straihgtness:0.015mm
7)Surface Chromium-Plating's Hardness After Nitriding:≥900HB
8)Chrominm-plating Depth:0.05-0.10mm
9)Alloy Hardness:HRC50-65
10)Alloy Depth:0.8-2.0mm

6 . As per customer's demand,we can also supply below:
PVC/PE Film Blowing Screw;

Blow Molding Screw;

PS/PE/PP/ABS Sheet Extrusion Screw;

PE Aluminum Plate;

PPR Pipe Screw;

EVA Extrusion Screw;

HDPE High efficiency Screw;

PET Straps Screw;

XPS/EPE Foamed Screw;

Granulation Screw,Vented single screw etc.
